Basic Specifications

---

Key Features & Advantages

1️⃣ IPS Wide Viewing Technology

The IPS panel ensures:

• 178° wide viewing angles

• Accurate color reproduction

• Stable brightness from all directions

• Reduced color distortion

Perfect for control panels and user interfaces where readability is critical.

---

2️⃣ 24-Bit RGB + 9-Bit SPI Interface

This dual-interface structure offers flexibility:

• 24-bit RGB: High-speed data transmission for smooth graphics display

• 9-bit SPI: Command control interface for simplified configuration

• Suitable for MCU and embedded system integration

Ideal for smart controllers, HMI systems, and industrial devices.

---

3️⃣ 350 nits Brightness

With 350 cd/m² brightness:

• Clear visibility in indoor environments

• Suitable for medical, industrial, and commercial smart devices

• Balanced power consumption and display clarity

---

4️⃣ Slim and Compact Structure

At only 4.25mm thickness, this module:

• Saves installation space

• Fits compact embedded systems

• Supports lightweight smart terminal designs

---

5️⃣ Optional Capacitive Touch Panel (TP Available)

The module supports:

• Projected capacitive touch (PCAP)

• Multi-touch functionality

• High sensitivity and smooth operation

Perfect for smart control panels, home automation systems, handheld terminals, and IoT devices.

---

Typical Applications

• Smart home control panels

• Industrial control interfaces

• Medical monitoring equipment

• Handheld terminals

• Smart appliances

• Embedded HMI systems

---

Why Choose This 5-Inch TFT LCD Module?

✔ IPS wide viewing angle
✔ Compact and lightweight structure
✔ Dual interface flexibility
✔ Industrial temperature support
✔ Touch panel customization available
✔ Reliable ST7701S driver solution

---

If you need customized solutions such as:

• High brightness enhancement

• Optical bonding

• Custom FPC design

• Cover glass printing

• Interface modification

• Wide temperature version

This 5-inch TFT LCD module can be tailored to your project requirements.

---
